List of information - Central Unit
369
7SS52 V4 Manual
C53000-G1176-C182-1
176.1091 Timing error BF input $00 L1 (BF-
BIErr $00 L1)
BU OUT k g * * LED REL
176.1092 Timing error BF input $00 L2 (BF-
BIErr $00 L2)
BU OUT k g * * LED REL
176.1093 Timing error BF input $00 L3 (BF-
BIErr $00 L3)
BU OUT k g * * LED REL
176.1094 Timing error BF input $00 3pole
(BFBIErr $00 3P)
BU OUT k g * * LED REL
176.1101 Timing error BF release $00
1pole (BFRlErr $00 1P)
BU OUT k g * * LED REL
176.1102 Timing error BF release $00
3pole (BFRlErr $00 3P)
BU OUT k g * * LED REL
176.1104 Timing error BF impulse input $00
(BFBIImpErr $00)
BU OUT k g * * LED REL
176.1110 $01 Isolator $02 ($01 $02) BU DP k g * * LED REL
176.1112 Fault: run time $01 isolator $02
(FltR $01 $02)
BU OUT k * * LED REL
176.1113 Fault: dist. position $01 isolator
$02 (FltP $01 $02)
BU OUT k * * LED REL
176.1115 $01 Isolator $02 ($01 $02) BU DP k g * * LED REL
176.1117 Fault: run time $01 isolator $02
(FltR $01 $02)
BU OUT k * * LED REL
176.1118 Fault: dist. position $01 isolator
$02 (FltP $01 $02)
BU OUT k * * LED REL
176.1120 $01 Isolator $02 ($01 $02) BU DP k g * * LED REL
176.1122 Fault: run time $01 isolator $02
(FltR $01 $02)
BU OUT k * * LED REL
176.1123 Fault: dist. position $01 isolator
$02 (FltP $01 $02)
BU OUT k * * LED REL
176.1125 $01 Isolator $02 ($01 $02) BU DP k g * * LED REL
176.1127 Fault: run time $01 isolator $02
(FltR $01 $02)
BU OUT k * * LED REL
176.1128 Fault: dist. position $01 isolator
$02 (FltP $01 $02)
BU OUT k * * LED REL
176.1130 $01 Isolator $02 ($01 $02) BU DP k g * * LED REL
176.1132 Fault: run time $01 isolator $02
(FltR $01 $02)
BU OUT k * * LED REL
176.1133 Fault: dist. position $01 isolator
$02 (FltP $01 $02)
BU OUT k * * LED REL
176.1134 Failure of isolator aux. voltage
$00 (BayDC fail $00)
BU OUT k g * * LED REL
176.1135 $01 circuit breaker $02 ($01 $02) BU DP k g * * LED REL
176.1136 Circuit breaker fault $01 (CB fault
$01)
BU OUT k g * * LED REL
176.1141 Input 1 from $00 (IN1 BU $00) BU OUT * * * LED REL
176.1142 Output 1 to $00 (OUT1 BU $00) BU OUT * * * LED REL
176.1143 Input 2 from $00 (IN2 BU $00) BU OUT * * * LED REL
176.1144 Output 2 to $00 (OUT2 BU $00) BU OUT * * * LED REL
176.1145 Input 3 from $00 (IN3 BU $00) BU OUT * * * LED REL
176.1146 Output 3 to $00 (OUT3 BU $00) BU OUT * * * LED REL
176.1147 Input 4 from $00 (IN4 BU $00) BU OUT * * * LED REL
176.1148 Output 4 to $00 (OUT4 BU $00) BU OUT * * * LED REL
176.1171 15V supply supervision $00 (15V-
superv $00)
BU OUT k g * * LED REL
FNo. Description Function Type
ofIn-
for-
matio
n
Log-Buffer Configurable in Matrix IEC 60870-5-103
Event Log On/Off
Trip (Fault) Log On/Off
Ground Fault Log On/Off
Marked in Oscill. Record
LED
Binary Input
Function Key
Binary Output
Chatter Blocking
Type
Information No.
Data Unit
General Interrogation
