Siemens SIPROTEC 7SS523 V3.2

Appendix
368
7SS52 V4 Manual
C53000-G1176-C182-1
10480 Bus bar protection complete
blocked (BB prot blkd)
IEC61850-info OUT * * * LED BO
10481 BF protection complete blocked
(BF prot blkd)
IEC61850-info OUT * * * LED BO
10484 BB protection complete blocked
by error (BBP blckd err)
IEC61850-info OUT * * * LED BO
10485 BB protection partially blocked by
error (BBP Pblckd err)
IEC61850-info OUT * * * LED BO
10486 Timing error trip release (TripRel-
Err)
Monitoring OUT * * * LED BO 194 179 1 yes
10487 >TRIP-Release for external
command (>TRIP-Release)
BB Protection SP on
off
* * LED BI BO 194 159 1 yes
10488 BF protection complete blocked
by error (BF blckd err)
IEC61850-info OUT * * * LED BO
10489 BF protection partially blocked by
error (BF Pblckd err)
IEC61850-info OUT * * * LED BO
10490 >Blocking back-up breaker
fail.prot. BU (>Block BF of BU)
BF-Protection SP on
off
* * LED BI BO 194 167 1 yes
10491 Blocking back-up breaker
fail.prot. BU (Block BF of BU)
BF-Protection IntSP on
off
* * LED BO 194 168 1 yes
10492 Back-up breaker fail.prot. of BU
blocked (Blkd BF of BU)
BF-Protection OUT on
off
* * LED BO 194 169 1 yes
10493 >Blocking O/C protection of BU
(>Block O/C BU)
Protec. general SP on
off
* * LED BI BO 194 195 1 yes
10494 Blocking O/C protection of BU
(Block O/C BU)
Protec. general IntSP on
off
* * LED BO 194 196 1 yes
10495 O/C protection of BU blocked
(Blkd O/C BU)
Protec. general OUT on
off
* * LED BO 194 197 1 yes
10496 BF protection BZ blocked (group
alarm) (BF BZ blkd M)
BF-Protection OUT on
off
**LEDBO
10497 Trip command BZ blocked (group
alarm) (TRIP BZ blkd M)
BB Protection OUT on
off
**LEDBO
30053 Fault recording is running (Fault
rec. run.)
Osc. Fault Rec. OUT * * * LED BO
009.0100 Failure EN100 Modul (Failure
Modul)
EN100-Modul 1 IntSP on
off
**LEDBO
009.0101 Failure EN100 Link Channel 1
(Ch1) (Fail Ch1)
EN100-Modul 1 IntSP on
off
**LEDBO
009.0102 Failure EN100 Link Channel 2
(Ch2) (Fail Ch2)
EN100-Modul 1 IntSP on
off
**LEDBO
176.1061 Bay $00 out of service (OutOf-
Serv. $00)
BU OUT k g * * LED REL
176.1062 Maintenance of bay $00 (Main-
ten. $00)
BU OUT k g * * LED REL
176.1063 Bay unit $00 failure (BU fail $00) BU OUT k g * * LED REL
176.1071 Trip repeat $00 phase L1 (Tri-
pRep $00 L1)
BU OUT * k * LED REL
176.1072 Trip repeat $00 phase L2 (Tri-
pRep $00 L2)
BU OUT * k * LED REL
176.1073 Trip repeat $00 phase L3 (Tri-
pRep $00 L3)
BU OUT * k * LED REL
176.1081 No release of TRIP command
$00 (noTripRel $00)
BU OUT * k * LED REL
176.1082 Breaker failure/Transfer trip $00
(TransfTrip $00)
BU OUT * k * LED REL
FNo. Description Function Type
ofIn-
for-
matio
n
Log-Buffer Configurable in Matrix IEC 60870-5-103
Event Log On/Off
Trip (Fault) Log On/Off
Ground Fault Log On/Off
Marked in Oscill. Record
LED
Binary Input
Function Key
Binary Output
Chatter Blocking
Type
Information No.
Data Unit
General Interrogation
