Functions
162
7SS52 V4 Manual
C53000-G1176-C182-3
5.6.3 Settings for the Central Unit
5.6.4 Settings of the Bay Unit
5.6.5 List of Information from the Central Unit
Addr. Setting Title Setting Options Default Setting Comments
6401A fault rec mode global storage, local initiation
global storage, initiation by
CU
local storage, local initiation
global storage, ini-
tiation by CU
Mode of fault recording
6404 MAX. LENGTH 0.30 .. 5.00 sec 2.00 sec Max. length of a Waveform Cap-
ture Record
6405 PRE. TRIG. TIME 0.05 .. 0.50 sec 0.20 sec Captured Waveform Prior to
Trigger
6406 POST REC. TIME 0.05 .. 0.50 sec 0.20 sec Captured Waveform after Event
6407 BinIn CAPT.TIME 0.10 .. 5.00 sec; ∞ 0.40 sec Capture Time via Binary Input
Addr. Parameters Setting Options Default Settings Comments
7402 INITIATION STORAGE BY FD.
STORAGE BY TRIP
START WITH TRIP
STORAGE BY FD. Start/storage criterion for fault
recording
FNo. Alarm Comments
4 >Trig.Wave.Cap. >Trigger Waveform Capture
