Technical Data
314
7SS52 V4 Manual
C53000-G1176-C182-1
– Attenuated oscillation 2.5 kV (Peak Value), polarity alternating
IEC 60694, IEC 61000-4-12 100 kHz, 1 MHz, 10 MHz and 50 MHz,
R
I
= 200 Ω
– Discharge of static electricity 8 kV contact discharge;
IEC 60 55-22-2, Class IV 15 kV air discharge; both polarities;
und IEC 61000-4-2, Class IV 150 pF; R
I
= 330 Ω
– Irradiation with HF field, 10 V/m; 80 MHz to 1000 MHz;
frequency sweep 10 V/m; 800 MHz to 960 MHz;
IEC 60255-22-3, Class III 80% AM; 1kHz
IEC 61000-4-3, Class III
– Irradiation with HF field,
single frequencies IEC 60255-22-3, 10 V/m 80/160/450/900 MHz;
IEC 61000-4-3, amplitude-modulated r80 % AM 1 kHz; duty cycle > 10 s
Class III:
– Radiated Electromagnetic Interference 35 V/m; 25 MHz to 1000 MHz
IEEE Std C37.90.2
– Fast transient disturbance/Burst PE conductor: 1 kV / 5 kHz;
IEC 60255-22-4 and all circuits: 4 kV / 2.5 kHz;
IEC 61000-4-4 Class IV 5 / 50 ns; 5 kHz;
burst duration = 15 ms;
repetition rate 300 ms;
both polarities;
R
I
= 50 Ω; test duration 1 min
– High-energy surge voltages (SURGE), Impulse: 1.2/50 µs
IEC 61000-4-5 installation Class 3
Auxiliary voltage common mode: 2 kV; 12 Ω; 9 µF
diff. mode: 1 kV; 2 Ω; 18 µF
measuring inputs, binary inputs common mode: 2 kV; 42 Ω; 0.5 µF
und relay outputs diff. mode: 1 kV; 42 Ω; 0.5 µF
– HF on lines 10 V (r.m.s. value);
IEC 60255-22-6 150 kHz to 80 MHz; 80 %; 1 kHz; AM;
IEC 61000-4-6 Class III R
I
= 150 Ω
– Power system-frequency 30 A/m continuously;
magnetic field 300 A/m for 3 s; 50 Hz;
IEC 61000-4-8
IEC 255-6 Class IV
