List of Information - Bay Unit
375
7SS52 V4 Manual
C53000-G1176-C182-1
1780 Fault L13E O/C fault detection L1-L3-E on 2 60 40
1781 Fault L23 O/C fault detection L2-L3 on 2 60 41
1782 Fault L23E O/C fault detection L2-L3-E on 2 60 42
1783 Fault L123 O/C fault detection L1-L2-L3 on 2 60 43
1784 Fault L123E O/C fault detection L1-L2-L3-E on 2 60 44
1785 Fault E O/C fault detection E only on 2 60 45
1791 O/C Gen.Trip O/C general trip command on OT 2 CA TA p 68
1800 I>> Fault O/C fault detection stage I>> on OT
1801 I>> Fault L1 O/C fault detection stage I>> phase L1 OT 2 GI 60 46
1802 I>> Fault L2 O/C fault detection stage I>> phase L2 OT 2 GI 60 47
1803 I>> Fault L3 O/C fault detection stage I>> phase L3 OT 2 GI 60 48
1804 T-I>> expired O/C time TI>> expired on OT 2 60 49
1805 I>> Trip O/C protection I>> phase trip ) OT 2 CA p 91
1810 I> Fault O/C fault detection stage I> on OT
1811 I> Fault L1 O/C fault detection stage I> phase L1 OT 2 GI 60 50
1812 I> Fault L2 O/C fault detection stage I> phase L2 OT 2 GI 60 51
1813 I> Fault L3 O/C fault detection stage I> phase L3 OT 2 GI 60 52
1814 T-I> expired O/C time TI> expired v OT 2 60 53
1815 I> Trip O/C protection I> phase trip OT 2 CA p 90
1820 Ip Fault O/C fault detection Ip on OT
1821 Ip Fault L1 O/C fault detection Ip phase L1 OT 2 GI 60 54
1822 Ip Fault L2 O/C fault detection Ip phase L2 OT 2 GI 60 55
1823 Ip Fault L3 3 O/C fault detection Ip phase L3 OT 2 GI 60 56
1824 T-Ip expired O/C time TIp expired on OT 2 60 57
1825 Ip Trip O/C protection Ip phase trip OT 2 60 58
1831 IE>> Fault O/C fault detection IE>> earth on OT 2 GI 60 59
1832 T-IE>> expired O/C time TIE>> expired on OT 2 60 60
1833 IE>> Trip O/C protection IE>> earth trip OT 2 60 61
1834 IE> Fault O/C fault detection IE> earth on OT 2 GI 60 62
1835 T-IE> expired O/C time TIE> expired on OT 2 60 63
1836 IE> Trip O/C protection IE> earth trip OT 2 CA p 92
1837 IEp Fault O/C fault detection IEp earth on OT 2 GI 60 64
1838 T-IEp expired O/C time TIEp expired on OT 2 60 65
1839 IEp Trip O/C protection IEp earth trip OT 2 60 66
7601 >Isolator1on >Isolator 1 - position closed on/off IOT
7602 >Isolator1off >Isolator 1 - position open on/off IOT
7603 >Isolator2on >Isolator 2 - position closed on/off IOT
7604 >Isolator2off >Isolator 2 - position open on/off IOT
7605 >Isolator3on >Isolator 3 - position closed on/off IOT
7606 >Isolator3off >Isolator 3 - position open on/off IOT
7607 >Isolator4on >Isolator 4 - position closed on/off IOT
7608 >Isolator4off >Isolator 4 - position open on/off IOT
FNo. Short Text Logical Function Log Buffers Configurable
in Matrix
IEC 60870-5-103
Event Log On/Off
Measured Value
Trip (Fault) Log On/Off
Binary Input I
Binary Output O
(LED, alarm relay)
Trip Relay T
Data Unit
Compatible Annunciation
General Interrogation
Annunc. for Fault Rec. Buffer
(Tagged)
Type (p: Corresponds to
parameter “Function type“)
Information Number
To Next Page
