List of Information - Bay Unit
377
7SS52 V4 Manual
C53000-G1176-C182-1
7657 BB TRIP block TRIP commands of whole busbar blocked on/off OT
7658 SVS SS block. BF (ext.start) of whole busbar blocked on/off OT
7659 Test mode Test mode of protective functions on/off OT
7672 IDL1 [%] = BZ: Differential current phase L1 [%] M
7673 IDL2 [%] = BZ: Differential current phase L2 [%] M
7674 IDL3 [%] = BZ: Differential current phase L3 [%] M
7675 ISL1 [%] = BZ: Stabilizing current phase L1 [%] M
7676 ISL2 [%] = BZ: Stabilizing current phase L2 [%] M
7677 ISL3 [%] = BZ: Stabilizing current phase L3 [%] M
7678 IDL1 = BZ: Differential current phase L1 M
7679 IDL2 = BZ: Differential current phase L2 M
7680 IDL3 = BZ: Differential current phase L3 M
7681 ISL1 = BZ: Stabilizing current phase L1 M
7682 ISL2 = BZ: Stabilizing current phase L2 M
7683 ISL3 = BZ: Stabilizing current phase L3 M
7684 IL1= Normalized current IL1 = M
7685 IL2= Normalized current IL2 = M
7686 IL3= Normalized current IL3 = M
7687 IE= Normalized current IE = M
7690 >Blk.BF of BB >Block.BF (ex.start) of whole busbar on/off on IOT
7696 Annunc. 1 User defined annunciation 1 on/off OT
7697 Annunc. 2 User defined annunciation 2 on/off OT
7698 Annunc. 3 User defined annunciation 3 on/off OT
7699 Annunc. 4 User defined annunciation 4 on/off OT
FNo. Short Text Logical Function Log Buffers Configurable
in Matrix
IEC 60870-5-103
Event Log On/Off
Measured Value
Trip (Fault) Log On/Off
Binary Input I
Binary Output O
(LED, alarm relay)
Trip Relay T
Data Unit
Compatible Annunciation
General Interrogation
Annunc. for Fault Rec. Buffer
(Tagged)
Type (p: Corresponds to
parameter “Function type“)
Information Number
