Marshalling - Central Unit
395
7SS52 V4 Manual
C53000-G1176-C182-3
A.15 Marshalling - Central Unit
When the device leaves the factory, the annunciations for the binary inputs, relays,
LEDs and function keys are preallocated for the maximum scope. For the prealloca-
tion, please refer to Table A-22, page 395.
Table A-22 Marshalling of the Binary Inputs
Table A-23 Marshalling of the Relay
Binary
Input
Annunciation FNo. Comments
1 >Reset LED 5 Reset LED diplays
2 >Start FltRec 4 Start fault recording
3 >Time synchron 3 Time synchronization
4empty − empty
5empty − empty
6 >Reset Id-Block 10461 Reset blocking of diff-current
superv.
7
>Reset IsoMalBl 10465 >Reset blocking of isolator fault
8empty − empty
... ... ... ...
12 empty − empty
Relay Annunciation FNo. Comments
1 Err PROT BLOCK 10476 Error with protection blocking
2 Err PROT ACTIVE 10475 Error without protection blocking
3 BU fail M 10455 Bay unit failure
3 Meas sup BU M 10423 Measured value superv. BU
4 15V-superv CU 10420 15V supply supervision central unit
24V-superv CU 10421 24V supply supervision central unit
Batt. superv CU 10422 Battery supervision central unit
Supply sup BU M 10424 Supply voltage superv. BU
5 Flt autotest M 10429 Failure in auto testing
6 not assigned − not assigned
7 BF ImpBI errorM 10437 Timing error BF impulse input
BF rel error M 10435 Timing error BF release
BF BI error M 10434 Timing error BF input
8 Id-sup CZ M 10410 Diff-current superv. CZ
Id-sup BZ M 10415 Diff-current superv. BZ
