9.2.5 Overview of LEDs on High Feature 3RW5 HMI
Device LEDs (RN, ER, MT)
The display of the device LEDs of the 3RW5 HMI High Feature (Page 111) shows the status
summary for the following devices:
Ⴠ 3RW52 soft starter
Ⴠ 3RW5 communication module (if there is one)
Ⴠ 3RW5 HMI High Feature
Please note that the display of the device LEDs of the 3RW5 HMI High Feature does not
have to correlate with the display of the device LEDs of the 3RW52 soft starter.
Status LED
The display on the status LEDs of the 3RW5 HMI High Feature (Page 111) indicates the
state of the 3RW52 soft starter and the operating state of the motor.
Status
LED
Status of the 3RW52 soft starter
Motor operating state
Lights up
green
Operation The ramp up time comes to an end and the motor
is running.
Flashes
green
Starting or stopping time active Motor is ramping up or ramping down.
Additional information
You will find more information on the messages of the 3RW52 soft starter in the chapter
Status and error displays (Page 171).
You will find further information on the messages of the 3RW5 communication module in the
manual for the 3RW5 communication module in question.
