Technical data
11
Siemens Building Technologies
Fire Safety & Security Products 02.2009
EN
SISTORE MX 3G
Video compression
Colour resolution Video recording always takes place in YUV 4:2:2 true colour format.
The VGA board must be set to 16-bit mode (Hi-Color). Video compression is
made in JPEG format.
Video input 16 external composite inputs, YC signals are not supported.
Video output 4 outputs: CVBS, YC signals are not supported.
Video standard PAL
Video scanning frequency PAL 13,5 MHz
A/D conversion PAL 1/100 s (20 ms) per field
Geometric resolution PAL: 704 x 576 pixels with 2 fields
Optocoupler
Trigger and signal inputs
Number of trigger and signal inputs 16
Trigger edge Positive or negative
Triggering of interrupts Yes
Switching voltage 5 V ± 10 %
Switching current Max. 5 mA
Digital inputs
Number of digital inputs 4
Triggering of interrupts No
Digital outputs
Number of digital outputs 4
Output current 50 mA (max.), reversible fuse
Electrical isolation Up to 2500 V
SISTORE MX systems are configured for DHCP by default.
If there is no DHCP server in the network, select the menu sequence Administration>
Configuration, then click the button TCP/IP parameters in the Network tab and enter a permanent
IP address instead of DHCP. Otherwise there may be quite a long waiting time as the system will wait
for a reply from the non-existent DHCP server.
