Siemens SISTORE MX Installation Manual

Details for ordering
12
Siemens Building Technologies
Fire Safety & Security Products 02.2009
4 Details for ordering
4.1 SISTORE MX / MX DVD
Further products and accessories can be found in the Internet:
2Hwww.buildingtechnologies.siemens.com > Products & Systems > Electronic
Security > Catalogue Downloads.
Type Part no. Designation Weight*
Without DVD
SISTORE MX 3208 250/200 S24245-F5085-A2 Hybrid recorder, 8 analog cameras,
32 LAN cameras, 250 GB,
100 ips analog, 100 ips digital
approx. 11.0
kg
SISTORE MX 3216 500/200 S24245-F5085-A4 Hybrid recorder, 16 analog cameras,
32 LAN cameras, 500 GB,
100 ips analog, 100 ips digital
approx. 11.0
kg
SISTORE MX 3232 1000/200 S24245-F5085-A6 Hybrid recorder, 32 analog cameras,
32 LAN cameras, 1000 GB,
100 ips analog, 100 ips digital
approx. 11.0
kg
With DVD
SISTORE MX 3204 250/150
DVD
S24245-F5085-A1 Hybrid recorder, 4 analog cameras,
32 LAN cameras, 250 GB,
50 ips analog, 100 ips digital, with DVD
approx. 11.0
kg
SISTORE MX 3208 250/200
DVD
S24245-F5085-A3 Hybrid recorder, 8 analog cameras,
32 LAN cameras, 250 GB,
100 ips analog, 100 ips digital, with DVD
approx. 11.0
kg
SISTORE MX 3216 500/200
DVD
S24245-F5085-A5 Hybrid recorder, 16 analog cameras,
32 LAN cameras, 500 GB,
100 ips analog, 100 ips digital, with DVD
approx. 11.0
kg
SISTORE MX 3232 1000/200
DVD
S24245-F5085-A7 Hybrid recorder, 32 analog cameras,
32 LAN cameras, 1000 GB,
100 ips analog, 100 ips digital, with DVD
approx. 11.0
kg
* Unit incl. packing material, accessories that are included in the delivery, and documentation
All SISTORE MX models have enabled video output and SCSI functions and are
delivered without keyboard.
The part number (PN) of your SISTORE unit will be found on the rating plate on the bottom of the unit.
