Installation
27
Siemens Building Technologies
Fire Safety & Security Products 02.2009
EN
4 75 Ohm termination
Dipsw Assignment
1 VIN25
2 VIN26
3 VIN27
4 VIN28
5 75 Ohm termination
Dipsw Assignment
1 VIN5
2 VIN6
3 VIN7
4 VIN8
6 75 Ohm termination
Dipsw Assignment
1 VIN21
2 VIN22
3 VIN23
4 VIN24
7 75 Ohm termination
Dipsw Assignment
1 VIN1
2 VIN2
3 VIN3
4 VIN4
8 75 Ohm termination
Dipsw Assignment
1 VIN17
2 VIN18
3 VIN19
4 VIN20
