19.17.2 Open and close site plan
1. Click the button Show map
– OR –
2. Select Map in the View menu.
Î The site plan will be opened or closed.
NOTE
When the mouse pointer is moved across an object on the site plan, a tooltip is displayed. This tooltips
provides information on the corresponding object (object name and description, server IP address and
port).
NOTE
The site plan can also be displayed without a connection to a server. See Section
1.
1. Left-click on the desired site plan in the tree structure.
Î The site plan will be opened in the display window.
NOTE
When the mouse pointer is moved across an object on the site plan, a tooltip is displayed. This tooltips
provides information on the corresponding object (object name and description, server IP address and
port).
