Display mode functions
40
Siemens Building Technologies
Fire Safety & Security Products 01.2008
Reset default image parameters
Clicking the button Default image parameters resets all image parameter to their
default values.
1. Click on Default image parameters.
2. Click OK.
Î The settings have been saved.
10.9 Display reference image
A reference frame documents the setting of a camera (frame cut-out) at the time
when a reference frame was generated. Following installation and alignment of the
camera, the displayed reference frame section can be held and compared at any
time with the camera's current display locally on the server or by remote access
with SISTORE MX RemoteView.
Generate reference image
1. Select the menu sequence Administration -> Configuration -> Camera.
Î The camera configuration dialog appears.
Î The system automatically generates a camera frame and saves this under a
preset name. The frames are stored in the application's main directory (e.g.
C:\Programs\SIEMENS\ SISTORE) under the name camrefx.jgp, where x
stands for the camera number.
Display reference image
Displaying a saved reference frame is possible both on the server as well as with
SISTORE MX RemoteView.
Prerequisite:
z The user has „Replay“ and „Display“ authorization.
Additional prerequisites for SISTORE MX RemoteView:
z The PC is connected to a server.
z The live image of the camera is displayed.
1. Right-click on the image of the required camera.
Î A context menu will be opened.
2. Select Show reference frame from the context menu.
Î The reference image will now be displayed.
