Siemens SISTORE MX

Technical data
13
Siemens Building Technologies
Fire Safety & Security Products 01.2008
4 Technical data
SISTORE MX 3204 SISTORE MX 3208 - 3232
with 4 video inputs with 8, 16 or 32 video inputs
SISTORE MX 3204 SISTORE MX 3208 - 3232
Recording speed - analog max. 50 images per second,
configurable for analogue cameras
max. 100 images per second,
configurable for analogue cameras
Recording speed - digital max. 100 images per second, configurable for max. 32 LAN cameras
Video inputs 4 x CCVS (BNC sockets) enabled,
1 V
pp
/75 Ohm, max. 32 LAN cameras
8/16/32 x CCVS (BNC sockets) enabled,
1 V
pp
/75 Ohm, max. 32 LAN cameras
Outputs 1 x VGA, 2 x CCVS (BNC sockets) 1 x VGA, 4 x CCVS (BNC sockets)
Trigger inputs
16 U
in
: 5 – 24 V, max. 10 mA 32 U
in
: 5 – 24 V, max. 10 mA
Event control event-triggered recording of individual cameras or camera groups with
configurable time-slot pattern. Events:
z alarm contacts
z motion detection
z Time control
z TCP/IP command
Alarm signalling via monitor connection, digital output, LAN/WAN to RemoteView station
Digital inputs 4 for AND operations and system control
Uin: 5 – 24 V, max. 10 mA
8 for AND operations and system control
U
in
: 5 – 24 V, max. 10 mA
Digital outputs 8 alarm/key outputs,
configurable switching (rising or falling
edge duration)
U
out
5 – 24 V, max. 50 mA
16 alarm/key outputs,
configurable switching (rising or falling
edge duration)
U
out
5 – 24 V, max. 50 mA
Interfaces 2 x RS485, 1 x LAN, 4 x USB 2.0 (0.5 A), 1 x SCSI,
1 x VGA, 1 x Audio in, 1 x Mic in, 1 x Audio out,
optionally: S
0
interface for ISDN
Mouse, PC keyboard mouse with USB connection, virtual keyboard activated, USB keyboard (optional)
Video standard PAL/NTSC
Resolution standard: 352 x 288 pixels,
high resolution: 704 x 288 pixels
Compression M-JPEG, configurable: variable between 10 and 80 KB
Text overlay in the video image max. 16 characters
Font and background colours freely selectable
Storage media basic unit (E)IDE
