5 Uninterruptible 24 V power supply
Integration of a SITOP 24V power supply in PCS 7
Entry ID: 10948108, V3.2, 01/2019
Siemens AG
2019 All rights reserved
You can find the Generic Station Description in the item entitled GSD for SITOP
UPS1600 for integration in STEP 7 V5.
Parameterizing Ethernet nodes
The SITOP UPS1600 communicates by means of PROFINET IO on the
automation
the IP address and the device name of the UPS to the network configuration of the
fieldbus.
To parameterize the Ethernet nodes, they must be on the same physical network
as the ES. After this, you can make the separation between the plant bus and
the process bus (field level).
Proceed as follows:
1. Make sure that the device is on the same physical network as the ES.
2. In the SIMATIC Manager, execute the menu command "Target system > Edit
Ethernet Node".
