Siemens SIWAREX FTA - Page 108

Weighing Functions
SIWAREX FTA
5-96
Name
Type
Address
Default
Range of Values / Explanation
Reference
Dosing filter type
BYTE
DBB022
0
Filter type for dosage control
0: critically damped
1: Bessel-Filter
2: Butterworth Filter
Other definitions not permitted.
5.16.8
Dosing filter limit
frequency
BYTE
DBB023
2
0: No filter
1: fg = 20Hz
2: fg = 10Hz
3: fg = 5Hz
4: fg = 2Hz
5: fg = 1Hz
6: fg = 0,5Hz
7: fg = 0,2Hz
8: fg = 0.1Hz
9: fg = 0´.05Hz
Other definitions not permitted.
5.16.10
Tare / Zero setting
0
Tare / Zero setting mode
BYTE
DBB024
0
0: No taring, no zero setting at weighing start
1: Zero setting
2: Tare
3: Taring with average value
4: Taring using external entry tare
Other definitions not permitted.
5.16.11
Tare / Zero setting cycle
BYTE
DBB025
0
0: Every weighing is nullified or tared
1: Tipping is not nullified or tared
2...99: 2…99 tippings not nullified or tared
Other definitions not permitted.
5.16.12
Reserve 3
WORD
DBB026
0
Reserve 3
Tare min. weight
REAL
DBB028
0
Taring or ext. tare entries are only executed if
gross > tare minimum weight
0: No monitoring of the tare minimum weight
5.16.13
Tare max. weight
REAL
DBB032
0
Tarring or ext. Tare entries are only executed if
gross < tare maximum weight
0: No monitoring of the tare maximum weight
5.16.14
Cycle time for zero
setting
TIME
DBB036
300000
msec
If 0, then no time controlled zero setting
Unequal 0: Time between two zero settings
Note:
Zero setting / taring is performed after 15min at
the latest with weighing operating mode AWI and
country code “OIML”
5.16.15
Step control / check stop
Step control through
digital input 1
BYTE
DBB040
0
Instead of defined command codes for the digital
inputs, step-on conditions can be influenced
through the inputs for dosing control (prerequisite
in DR interface parameters is identification 0xFF).
0: Weighing waits at step 0 if DI1 is active;
1: Weighing waits at step 1 if DI1 is active
2: Weighing waits at step 2 if DI1 is active
...
7: Weighing waits at step 7 if DI1 is active
Other definitions not permitted.
5.16.16
Step control through
digital input 2
BYTE
DBB041
0
Instead of defined command codes for the digital
inputs, step-on conditions can be influenced
through the inputs for weighing control
(prerequisite in DR interface parameters is
identification 0xFF).
0: Weighing waits at step 0 if DI2 is active;
1: Weighing waits at step 1 if DI2 is active
2: Weighing waits at step 2 if DI2 is active
...
7: Weighing waits at step 7 if DI2 is active
Other definitions not permitted.
5.16.16
