Weighing Functions
SIWAREX FTA
5-97
Name
Type
Address
Default
Range of Values / Explanation
Reference
Step control through
digital input 3
BYTE
DBB042
0
Instead of defined command codes for the digital
inputs, step-on conditions can be influenced
through the inputs for weighing control
(prerequisite in DR interface parameters is
identification 0xFF).
0: Weighing waits at step 0 if DI3 is active;
1: Weighing waits at step 1 if DI3 is active
2: Weighing waits at step 2 if DI3 is active
...
7: Weighing waits at step 7 if DI3 is active
Other definitions not permitted.
5.16.16
Step control through
digital input 4
BYTE
DBB043
0
Instead of defined command codes for the digital
inputs, step-on conditions can be influenced
through the inputs for weighing control
(prerequisite in DR interface parameters is
identification 0xFF).
0: Weighing waits at step 0 if DI4 is active;
1: Weighing waits at step 1 if DI4 is active
2: Weighing waits at step 2 if DI4 is active
...
7: Weighing waits at step 7 if DI4 is active
Other definitions not permitted.
5.16.16
Step control through
digital input 5
BYTE
DBB044
0
Instead of defined command codes for the digital
inputs, step-on conditions can be influenced
through the inputs for weighing control
(prerequisite in DR interface parameters is
identification 0xFF).
0: Weighing waits at step 0 if DI5 is active;
1: Weighing waits at step 1 if DI5 is active
2: Weighing waits at step 2 if DI5 is active
...
7: Weighing waits at step 7 if DI5 is active
Other definitions not permitted.
5.16.16
Step control through
digital input 6
BYTE
DBB045
0
Instead of defined command codes for the digital
inputs, step-on conditions can be influenced
through the inputs for weighing control
(prerequisite in DR interface parameters is
identification 0xFF).
0: Weighing waits at step 0 if DI6 is active;
1: Weighing waits at step 1 if DI6 is active
2: Weighing waits at step 2 if DI6 is active
...
7: Weighing waits at step 7 if DI6 is active
Other definitions not permitted.
5.16.16
Step control through
digital input 7
BYTE
DBB046
0
Instead of defined command codes for the digital
inputs, step-on conditions can be influenced
through the inputs for weighing control
(prerequisite in DR interface parameters is
identification 0xFF).
0: Weighing waits at step 0 if DI7 is active;
1: Weighing waits at step 1 if DI7 is active
2: Weighing waits at step 2 if DI7 is active
...
7: Weighing waits at step 7 if DI7 is active
Other definitions not permitted.
5.16.16
Reserve 4
BYTE
DBB047
0
Reserve 4
Monitoring time step
control
TIME
DBB048
0
0: No monitoring
>0 Time definition for the monitoring
If no further stepping to the next weighing step is
performed within the defined time then the “Step-
on Timeout” technology error is generated.
5.16.17
