Weighing Functions
SIWAREX FTA
5-98
Name
Type
Address
Default
Range of Values / Explanation
Reference
Definition check stop
BYTE
DBB052
0
Bit 0 : No check stop
Bit 1 : Weighing goes to check stop after step 1
Bit 2 : Weighing goes to check stop after step 2
...
Bit 7 : Weighing goes to check stop after step 7
Other definitions not permitted.
5.16.18
Reserve 5
BYTE
DBB053
0
Reserve 5
Post dosing tolerance
check
Automatic dosing
Dosing method
Stop if more than TO1
Stop if more than TO2
Stop for more than TU1
Stop for more than TU2
Continue after TOL-Stop
BYTE
DBB054
0
Bit 0 :
0: No automatic post dosing
1: autom. post dosing for Tol-1 deviation
Bit 1 :
0: post dosing with continuous
fine signal
1: post dosing pulse mode
Bit 2 :
0: Weighing procedures not stopped
because of tolerance errors
1: Weighing stopped because of tolerance error
(weight above TO1)
Bit 3 :
0: autom. Weighing procedures not stopped
because of tolerance errors
1: Weighing stopped because of tolerance error
(weight above TO2)
Bit 4:
0: Weighing procedures are not stopped because
of tolerance errors
1: Weighing procedure is stopped because of
tolerance error (weight under TU1)
Bit 5:
0: autom. weighing procedures are not stopped
because of tolerance errors
1: Weighing procedure is stopped after a filling
procedure because of a tolerance error (weight
under TU2)
Bit 6:
0: Cycle cannot be continued when the TOL error
persists
1: Cycle can be continued even though the TOL
error exists
Bit 7 not used
5.16.19
5.16.20
5.16.21
5.16.22
5.16.23
5.16.24
5.16.25
Control pause
BYTE
DBB055
0
0: All weighing procedures are checked for
tolerance deviations
1: A weighing procedure is not checked for
tolerance deviations
2...98: 2...98 weighing procedures are not
checked for tolerance deviations, 99 no check
Other definitions not permitted.
5.16.26
Pulse duration for pulse
dosing
TIME
DBD056
1000 msec
Pulse duration of fine signal (in msec)
5.16.27
Controller
Controller behaviour at
scale fault
BYTE
DBB060
0
Bit 0 :
0: Reset controller for technology error
(weighing fault)
1: Limit controller to max. Access
5.16.28
