Technical Data
SIWAREX FTA
14-186
14.9 Dimensions and Weight
Dimensions W x H x D
80 x 125 x130 mm
Weight
600 g
Table 14-9 Data: Dimensions and Weight
14.10 Mechanical requirements and data
Testing
Standards
Test values
Vibration in operation
DIN IEC 60068-2-6
EC 60721-3-3, class 3M3
IEC 61131-2
Testing Fc
10 ... 58 Hz: 0.075 mm
amplitude
58 ...150 Hz: 9.8 m/s
2
10 cycles per axis
1 octave / min.
Shock in operation
DIN IEC 60068-2-27
EC 60721-3-3, class 3M3
IEC 61131-2
Test Ea
150 m/s
2
, Half sinus
Duration: 11 msec
Number: 3 per axis each
in neg. and pos. directions
Vibration in transportation
DIN IEC 60068-2-6
EC 60721-3-2, class 2M2
IEC 61131-2
Testing Fc
5 ... 9 Hz: 3.5 mm amplitude
9 ...5000 Hz: 9.8 m/s
2
10 cycles per axis
1 octave / min.
Shock in transportation
DIN IEC 60068-2-29
EC 60721-3-2, class 2M2
IEC 61131-2
Test Eb
250 m/s
2
, Half sinus
Duration: 6 msec
Number: 1000 per axis each
Falling
DIN IEC 60000-2-32
IEC 61131-2
Test Ed
High: 1 m
Number of trails: 5
Shipping package
Table 14-10 Data: Mechanical requirements
