Siemens SIWAREX FTA - Page 88

Weighing Functions
SIWAREX FTA
5-76
Name
Type
Address
Default
Range of Values / Explanation
Reference
RS485-character parity
RS485-Data-Bits
RS485-Stop-Bits
BYTE
DBB047
0
1
0
Bit 0 :
0: Even
1: odd
Bit 1 :
0: 7 data bits
1: 8 data bits
Bit 2 :
0: 1 Stop Bit
1: 2 Stop Bits
Bit 3 - 7 not used
5.6.18
Digital outputs
0
Definition of digital output
1
BYTE
DBB048
0FFh
Value range 00h – 3Fh
0...1Fh Bit-No. NAWI status flag
20h...3Fh Bit-No. AWI status flag
FDh Start cycl. transfer DigLC
FEh Stop cycl.transfer DigLC
FFh Output always inactive
Range of values 40h – FCh not permitted
5.6.19
Definition of digital output
2
BYTE
DBB049
0FFh
Value range 00h – 3Fh
0...1Fh Bit-No. NAWI status flag
20h...3Fh Bit-No. AWI status flag
FDh Start cycl. transfer DigLC
FEh Stop cycl. transfer DigLC
FFh Output always inactive
Range of values 40h – FCh not permitted
5.6.19
Definition of digital output
3
BYTE
DBB050
0FFh
Value range 00h – 3Fh
0...1Fh Bit-No. NAWI status flag
20h...3Fh Bit-No. AWI status flag
FDh Start cycl. transfer DigLC
FEh Stop cycl. transfer DigLC
FFh Output always inactive
Range of values 40h – FCh not permitted
5.6.19
Definition of digital output
4
BYTE
DBB051
0FFh
Value range 00h – 3Fh
0...1Fh Bit-No. NAWI status flag
20h...3Fh Bit-No. AWI status flag
FDh Start cycl. transfer DigLC
FEh Stop cycl.transfer DigLC
FFh Output always inactive
Range of values 40h – FCh not permitted
5.6.19
Definition of digital output
5
BYTE
DBB052
0FFh
Value range 00h – 3Fh
0...1Fh Bit-No. NAWI status flag
20h...3Fh Bit-No. AWI status flag
FDh Start cycl. transfer DigLC
FEh Stop cycl. transfer DigLC
FFh Output always inactive
Range of values 40h – FCh not permitted
5.6.19
Definition of digital output
6
BYTE
DBB053
0FFh
Value range 00h – 3Fh
0...1Fh Bit-No. NAWI status flag
20h...3Fh Bit-No. AWI status flag
FDh Start cycl. transfer DigLC
FEh Stop cycl. transfer DigLC
FFh Output always inactive
Range of values 40h – FCh not permitted
5.6.19
Definition of digital output
7
BYTE
DBB054
0FFh
Value range 00h – 3Fh
0...1Fh Bit-No. NAWI status flag
20h...3Fh Bit-No. AWI status flag
FDh Start cycl. transfer DigLC
FEh Stop cycl. transfer DigLC
FFh Output always inactive
Range of values 40h – FCh not permitted
5.6.19
Definition of digital output
8
BYTE
DBB055
0FFh
Value range 00h – 3Fh
0...1Fh Bit-No. NAWI status flag
20h...3Fh Bit-No. AWI status flag
5.6.19
