Weighing Functions
SIWAREX FTA
5-77
Name
Type
Address
Default
Range of Values / Explanation
Reference
FDh Start cycl. transfer DigLC
FEh Stop cycl. transfer DigLC
FFh Output always inactive
Range of values 40h – FCh not permitted
Level definition for digital
outputs 1....8
BYTE
DBB056
0
Bit 0 : DA1 -> 0 = high active: 1 = low active
....
Bit 7 : DA8 -> 0 = high active: 1 = low active
5.6.20
Replacement values for
digital outputs 1 .... 8
upon fault or OD signal
BYTE
DBB057
0
Bit 0 : Replace value digital output 1
....
Bit 7 : Replace value digital output 8
5.6.21
Activate - Digital output
replacement values for
operational faults
BYTE
DBB058
0
Bit 0 :
0: Replacement output upon operating error
deactivated
1: Replacement output upon operating error
activated
Bit 1 - 7 not used
5.6.22
Reserve 3
BYTE
DBB059
0
Reserve 3
Digital inputs
0
Definition of digital input 1
BYTE
DBB060
0
0 = No command
1- 254 = Command code
255 = Step-on condition. (see DR -7 Scale
parameter/Step control 5.16.16)
5.6.23
Definition of digital input 2
BYTE
DBB061
0
0 = No command
1- 254 = Command code
255 = Step-on condition. (see DR - Scale
parameter/Step control)
5.6.23
Definition of digital input 3
BYTE
DBB062
0
0 = No command
1- 254 = Command code
255 = Step-on condition. (see DR - Scale
parameter/Step control)
5.6.23
Definition of digital input 4
BYTE
DBB063
0
0 = No command
1- 254 = Command code
255 = Step-on condition. (see DR - Scale
parameter/Step control)
5.6.23
Definition of digital input 5
BYTE
DBB064
0
0 = No command
1- 254 = Command code
255 = Step-on condition. (see DR - Scale
parameter/Step control)
5.6.23
Definition of digital input 6
BYTE
DBB065
0
0 = No command
1- 254 = Command code
255 = Step-on condition. (see DR - Scale
parameter/Step control)
5.6.23
Definition of digital input 7
BYTE
DBB066
0
0 = No command
1- 254 = Command code
255 = Step-on condition. (see DR - Scale
parameter/Step control)
5.6.23
Level definition for digital
inputs 1...7
BYTE
DBB067
0
Bit 0 : Digital input 1 -> 0 = high active: 1 = low
active
....
Bit 6 : Digital input 7 -> 0 = high active: 1 = low
active
Bit 7 : not used.
5.6.24
Measurement time for
pulse input
TIME
DBB068
1 sec
100 to 10000 ms
Other definitions not permitted.
5.6.25
Reserve 4
DWORD
DBB072
0
Reserve 4
MMC Parameter
0
Log overflow
BYTE
DBB076
3
Bit 0 :
0: with full memory, the logging procedures are
stopped
1: with full memory, the oldest entries are
5.6.26
