Siemens WT46W430FF - Replacing Left; Right Side Panel

Repairs
2015-09-07 / DIS 113_58300000171499_ara_en_c Copyright by BSH Hausgeräte GmbH Page 37 of 65
6.4 Replacing left / right side panel
Prerequisite:
• Worktop has been removed.
• Fascia has been removed.
6.4.1 Removing left / right side panel
Remove screws [ 1]
Pull side panel backwards out of the catch elements [ 2]
Graphic 15:Side panel
1 Retaining screws 2 Locking points
1. Remove side panel.
.
