Repairs
2015-09-07 / DIS 113_58300000171499_ara_en_c Copyright by BSH Hausgeräte GmbH Page 59 of 65
6.19 Cleaning condenser
Prerequisite:
• Left and right side panels have been removed.
1.
2. Using a knife, cut out bottom group along the specified contour.
3. Carefully remove fluff from the evaporator.
4. Install maintenance door ([ 646776] ).
.
Gills coated with paint.
Do not damage this coating when cleaning.
