Siko AG05 - Page 57

Communication via SIKONETZ5
AG05 Date: 15.06.2016 Art. No. 85677 Mod. status 139/16 Page 57 of 64
Para-
meter
no.
[hex]
Name
Access
Format
Description
0x00
Node address
rw
Unsigned8
Value range 0 - 31
Setting of node address
Parameter changes become active only
after cold start or software reset.
(see chapter 8: Parameter description 
Parameter no. 22)
0x01
Baud rate
rw
Unsigned8
Setting the baud rate
0 = 19200
1 = 57600
2 = 115200
Parameter changes become active only
after cold start or software reset.
(see chapter 8: Parameter description 
Parameter no. 33)
0x02
Bus Timeout
rw
Unsigned16
Value range 0 – 20
(see chapter 8: Parameter description 
Parameter no. 35)
0x03
Reply
parameter to
write set
point
command
rw
Unsigned8
0 = Set point
1 = Actual value
2 = Output stage temperature
3 = Control voltage
4 = Output stage voltage
5 = Battery voltage
6 = Motor current
7 = Actual position
8 = Actual rotational speed
(see chapter 8: Parameter description 
Parameter no. 36)
0x04
Enable keys
time
rw
Unsigned8
Value range 1 – 60
(see chapter 8: Parameter description 
Parameter no. 37)
0x05
Key function
enable
rw
Unsigned8
0 = key function free
1 = key function locked
(see chapter 8: Parameter description 
Parameter no. 38)
0x07
LED 2 orange
rw
Unsigned8
0 = LED 2 Off
1 = LED 2 On
(see chapter 8: Parameter description 
Parameter no. 39)
0x08
LED 1 red
rw
Unsigned8
0 = LED 1 red Off
1 = LED 1 red On
(see chapter 8: Parameter description 
Parameter no. 40)
