Communication via SIKONETZ5
AG05 Date: 15.06.2016 Art. No. 85677 Mod. status 139/16 Page 58 of 64
Para-
meter
no.
[hex]
Name
Access
Format
Description
0x09
LED 1 green
rw
Unsigned8
0 = LED 1 green Off
1 = LED 1 green On
(see chapter 8: Parameter description 
Parameter no. 41)
0x0A
Decimal
places
rw
Unsigned8
Value range 0 – 4
(see chapter 8: Parameter description 
Parameter no. 42)
0x0B
Display divisor
rw
Unsigned8
Value range 0 – 3
(see chapter 8: Parameter description 
Parameter no. 43)
0x0C
Direction
indication
function
rw
Unsigned8
Value range 0 – 2
(see chapter 8: Parameter description 
Parameter no. 44)
0x0D
Display
orientation
rw
Unsigned8
0 = normal
1 = rotated by 180°
(see chapter 8: Parameter description 
Parameter no. 45)
0x0E
Programming
mode
configuration
rw
Unsigned8
0 = no programming mode
1 = apply programming mode
(see chapter 8: Parameter description 
Parameter no. 46)
0x0F
PIN change
rw
Unsigned32
Value range 0 – 99999
(see chapter 8: Parameter description 
Parameter no. 48)
0x10
Controller
parameter P
rw
Unsigned16
Value range 1 – 500
(see chapter 8: Parameter description 
Parameter no. 1)
0x11
Controller
parameter I
rw
Unsigned16
Value range 0 – 500
(see chapter 8: Parameter description 
Parameter no. 2)
0x12
Controller
parameter D
rw
Unsigned16
Value range 0 – 500
(see chapter 8: Parameter description 
Parameter no. 3)
0x13
a - Pos
rw
Unsigned8
Value range 1 – 100
(see chapter 8: Parameter description 
Parameter no. 4)
0x14
v - Pos
rw
Unsigned8
Gear 66:1  value range: 1 - 75
Gear 98:1  value range: 1 – 50
(see chapter 8: Parameter description 
Parameter no. 5)
0x15
a - rot
rw
Unsigned8
Value range 1 – 100
(see chapter 8: Parameter description 
Parameter no. 6)
