Para-
meter
no.
[hex]
Name
Access
Format
Description
0x16
a - inch
rw
Unsigned8
Value range 1 – 100
(see chapter 8: Parameter description 
Parameter no. 8)
0x17
v - inch
rw
Unsigned8
Gear 66:1  value range: 1 - 75
Gear 98:1  value range: 1 – 50
(see chapter 8: Parameter description 
Parameter no. 9)
0x18
ü - Numerator
rw
Unsigned16
Value range 1 – 10000
(see chapter 8: Parameter description 
Parameter no. 11)
0x19
ü -
Denominator
rw
Unsigned16
Value range 1 – 10000
(see chapter 8: Parameter description 
Parameter no. 12)
0x1A
Encoder
resolution
ro
Unsigned16
Constant Value 720
0x1B
Sense of
rotation
rw
Unsigned8
0 = i sense of rotation (cw)
1 = e sense of rotation (ccw)
(see chapter 8: Parameter description 
Parameter no. 18)
0x1C
Spindle pitch
rw
Unsigned16
Value range 0 – 1000000
(see chapter 8: Parameter description 
Parameter no. 13)
0x1E
Offset
rw
Integer32
Value range -999999 … 999999
(see chapter 8: Parameter description 
Parameter no. 32)
0x1F
Calibration
value
rw
Integer32
Value range -999999 … 999999
(see chapter 8: Parameter description 
Parameter no. 14)
0x20
Pos- window
rw
Unsigned16
Value range 0 – 1000
(see chapter 8: Parameter description 
Parameter no. 10)
0x21
Pos type
rw
Unsigned8
0 = direct
1 = loop +
2 = loop –
(see chapter 8: Parameter description 
Parameter no. 19)
0x22
Loop length
rw
Unsigned16
Value range 0 – 30000
(see chapter 8: Parameter description 
Parameter no. 27)
0x23
Inpos mode
rw
Unsigned8
0 = position control
1 = short circuit of the motor windings
2 = motor activated
(see chapter 8: Parameter description 
Parameter no. 26)
