84 007-5832-002
A: Technical Specifications and Pinouts
Table A-5 VGA Pin Functions
Pin Number Function
1Red
2 Green
3Blue
4N/C
5Ground
6Ground
7Ground
8Ground
9Ground
10 Ground
11 N/C
12 DDCDAT
13 HSYNC
14 VSYNC
15 DDCCLK
