Silicon Graphics UV 2000 User Manual

30 007-5832-002
2: System Control
blade installed. The CMC provides data collected from the compute nodes within the IRU to the
system management node upon request.
CMCs can communicate with the blade BMCs and other IRU CMCs when they are linked together
under a single system image (SSI); also called a partition. Each CMC shares its information with
the SMN as well as other CMCs within the SSI. Note that the system management node (server),
optional mass storage units and PCIe expansion enclosures do not have a CMC installed.
Figure 2-2 SGI UV 2000 LAN-attached System Control Network Example
Remote
workstation
monitor
Local Area Network (LAN)
Local Area Network (LAN)
Cat-5 Ethernet
SGI UV 2000 system
SGI UV 2000
