SGI UV 2000 Series NUMAlink Octal Router Chassis
007-5832-002 59
Figure 5-2 SGI UV 2000 Optional ORC Chassis Example (Front View)
Note: The NUMAlink unit’s CMC is connected to the CMC in each IRU installed in the rack.
7
6
5
4
3
2
1
0
