1: Operation Procedures
Figure 1-4 shows examples of the three-phase PDUs that can be used in the SGI UV 2000 system.
These PDUs are used to distribute power to the IRUs when the system is configured with
three-phase power. The enlarged section shows an optional PDU status interface panel.
Figure 1-4 Three-Phase PDU Examples
