3: System Overview
Optional BaseIO SSDs
The BaseIO blade can be configured with one or two internal 1.8-inch solid state drives (SSDs).
The SSDs can be configured as JBOD or RAID1. The RAID1 SSD pair is a software RAID1 and
two SSDs must be ordered with the system BaseIO to enable this configuration.
Figure 3-6 BaseIO Riser Enabled Blade Front Panel Example
USB
2
1
0
SAS0-3 SAS4-7
VGA
SERIAL
LAN1
LAN0 BMC
PCIE
