10-4
ME0456 is a 4100ES style Switch/LED display module specifically designed for fan
control. It complies with the requirements of AS 1668.1, 1998. It has rotary switches and
LEDs for 4 fans. In order to accommodate the required rotary switches, the front plate is
joggled forward so that it protrudes through the trim.
{xe "service port: software modes"}{xe "software modes"}
The Fan Control switch positions of ON, AUTO and OFF, as per the standard, are
permanently marked on the faceplate label.
The labelling of the LEDs, ON, FLT, and OFF is marked on the removable fan name
label card, LB0605, supplied with the module.
The card may be reversed and different LED labelling used, e.g., as required for damper
controls.
The name area accommodates 3 rows of 6 letters at 5mm text height.
A “soft” version of this label is available on the Fireplace website
(https://www.tycosafetyproducts-anz.com) as LB0605. This template allows entry of the
fan name on a PC for local printing. LED names may also be revised.
The Fan Control module mounts to the frame of the 4100ES Expansion bay door, from
the front, by the studs on the module with the nuts and washers provided.
Connection from “Out” of the adjacent Switch/LED module (or 64/64 Controller if it is
the first module on that Controller) to “In” on the module is by the flat flexible cable
provided (SX0039).
{xe "service port: software modes"}{xe "software modes"}
The Module is programmed as a standard 4100-1282 8 Switch/16 LED module. Up to 4
can be driven by one 64/64 Switch/LED Controller.
Each fan control with one rotary switch uses two of the 8 “switches”, and 3 of the 16
LEDs of an 8 Switch/16 LED module as per Table 9-1. The other 4 LEDs are not fitted so
must not be programmed.
Table 10-1. Switch/LED Format
Fan Control Switches LEDs
ON FLT OFF
1 SW1, SW2 LD1 LD2 LD3
2 SW3, SW4 LD5 LD6 LD7
3 SW5, SW6 LD9 LD10 LD11
4 SW7, SW8 LD13 LD14 LD15
The switch functions for Fan Control 1 are shown in Table 9-2. The state with both
switches closed is not physically achievable.
Table 10-2. Switch Status
SW1 SW2 Control Status
Closed (up) Open (centre) On
Open (centre) Closed (up) Off
Open (centre) Open (centre) Auto
Continued on next page
4100ES Fan Control Module {xe "service port: software modes"}{xe
"software modes"}
Overview
Labeling
Mounting &
Connection
Programming
