Simplex 4100ES Installation & Maintenance

K-3
Possible DescriptionOrderCode
Markingsonfor
thepartReplacement
Spare Part
NetworkingModules
565‐407
565‐516
4100‐6014
4100Modular NetworkInterfacecard 4100‐6078
565‐413 4100RS485WiredMediaModule 4100‐6056
565‐261 4100FibreOpticMediaModule 4100‐6057
4100‐6072
743‐716
FibreOpticMODEM
LeftportSingleMode 4100‐6072
4100‐6073
743‐717
FibreOpticMODEMRightportSingleMode 4100‐6073
Looms,BaysandWiringParts
733‐542 96"8wayLegacyCabinettoLegacyCabinet
Harness
733‐542
733‐952 SPStoAlarmRelayboardHarness 733‐952
733‐996 SPS
toCPUMotherboardHarness 733‐996
734‐008 2ft4wayPDIBaytoPDIBayHarness 734‐008
734‐075 8ft4wayPDICabinettoPDICabinet
Harness
734‐075
734‐078 TICtoLegacyCardPowerand Comms
Harness
734‐078
None ExpansionBay(PDI)for19”Cabinet
(old
stylefrontmount)
4100‐KT0446
None ExpansionBay(PDI)for19”Cabinet
(newstylerearmount)
4100‐KT0446
None Legacymotherboardmountingkit 4100‐KT0468
none FerriteBeadsingle 740‐836
none FerriteBeads(setof3) 4100‐5129
Spare Part
Order Codes
Continued

Simplex 4100ES Specifications

General

Type	Fire Alarm Control Panel
Display	LCD
Battery Backup	Yes
Model	4100ES
Manufacturer	Simplex
Communication Protocol	Optional Ethernet
Signaling Line Circuits (SLCs)	Up to 10
Notification Appliance Circuits (NACs)	Up to 10
Agency Listings	UL, FM, CSFM, MEA
Max Relay Circuits	20
Communication Ports	Ethernet
Operating Temperature	32°F to 120°F (0°C to 49°C)
Humidity	Up to 93% RH, non-condensing
