4100ES FIP cabinets contain the CPU, Operator Interface, system power supply (SPS),
backup batteries, and any additional modules that the panel requires. The FIP is the
central hub (often referred to as a host panel) of a standalone or MINIPLEX fire alarm
system. In a networked system, the FIP can be connected to other FIPs, so that each host
panel is a node on the network.
In the Australian 4100ES, the SPS is fitted to a bracket behind the hinged 8U door that
has the InfoAlarm operator I/F on it. The CPU Motherboard is fitted to the right hand
side of an expansion bay mounted directly below the power supply bay. This bay has a
PDI fitted so can house 4”x 5”cards as well as legacy cards.
Continued on next page
Introduction to FIPs (4100ES)
Overview
CPU Bay

Simplex 4100ES Specifications

General

Type	Fire Alarm Control Panel
Display	LCD
Battery Backup	Yes
Model	4100ES
Manufacturer	Simplex
Communication Protocol	Optional Ethernet
Signaling Line Circuits (SLCs)	Up to 10
Notification Appliance Circuits (NACs)	Up to 10
Agency Listings	UL, FM, CSFM, MEA
Max Relay Circuits	20
Communication Ports	Ethernet
Operating Temperature	32°F to 120°F (0°C to 49°C)
Humidity	Up to 93% RH, non-condensing
