Appendix C Compatible actuating
devices
MX Addressable Devices
The 4100ESi supports a maximum of 250 MX devices on a loop, and 2000 points on a CPU.
The number of devices on an MX loop can be limited to less than 250 devices depending on the
characteristics and loading of the devices configured. Use the 4100Cost tool to validate a loop design.
Maximum number of
devices on a loop
850PH Photoelectric Smoke and Heat detector
– SCI.
850P Photoelectric Smoke – SCI.
850H Heat detector – SCI.
850PC Photoelectric Smoke, Heat, CO detector
– SCI.
MX Addressable Field Devices
Maximum number of
devices on a loop
MIM800 Monitored Input Module.
CIM800 Contact Input Module.
RIM800 Relay Output Module.
SNM800 Sounder Notification Module.
DIM800 Detector Input Module.
DDM800 Detector Device Module.
LIM800 Loop Isolator Module.
MX Addressable Sounders and Beacons
Maximum number of
devices on a loop
LPAV3000 Sounder-Beacon Base.
LPSY800R Symphonic Sounder Red.
LPSY800W Symphonic Sounder-White.
LPSY865 Symphonic Sounder IP65.
LPAV800R Symphonic Sounder
Beacon-Red.
LPAV800W Symphonic Sounder
Beacon-White.
LPAV865 Symphonic Sounder IP65.
