Simplex 4100ESi Installation Guide

81
Conventional (collective) Detectors
Johnson Controls
Conventional
Detector Type
DIM800 MX
Monitor ZAM
(24VDC powered)
DDM800MX
Monitor ZAM
(Loop powered, low
voltage detectors)
4100-5004
8 Zone Module
614CH CO/Heat
Detector
32
21
37
614I Ionization
Detector
38
25
40
614P
Photo-electric
Detector
25
25
28
T614 Heat
Detector
Type A,B, C, D
23
17
30
Hard contact
devices
DIM800 MX
Monitor ZAM
(24VDC powered)
DDM800MX
Monitor ZAM
(Loop powered, low
voltage detectors)
4100-5004
8 Zone Module
T54B, B111, etc.
40
40
40
OSID, Vesda, etc.
*1
40
40
40
*1 It is recommended that these hard contact devices are limited to one device on a circuit.
Remote Indicators
The Johnson Controls E5xx range of Remote Indicators is suitable for use with the Johnson Controls
MX addressable and conventional actuating devices.
Compatible devices for upgrades
The MX devices listed above must be used for AS7240 compliant installations.
For upgrades or additions to existing sites the 4100ESi is compatible with a range of legacy IDNet and
MAPNET addressable sensors and devices.
The DDM800, DIM800, and 4100-5004 conventional interface cards are compatible with a range of
conventional detectors manufactured by Johnson Controls and other manufacturers.
For a complete list of compatible devices refer to the TSP-LT001 Device Compatibility Guide.
For information about upgrading legacy 4100 sites refer to the LT0620 4100ESi Service and
Upgrade Manual.
Both documents are available on www.tycosafetyproducts-anz.com
or call 1300 725 688 to speak to
a customer service representative.
