Simplex 4100ESi Installation Guide

73
Appendix A System specifications
Panel type
Includes
Standard 4100ESi Series Fire Alarm Panels
4100-FP1045.
Compact 4100ESi- CPU, 10A PSU, 1 MX Loop, 15U Titania
CAB, MCP, 1x8 Slot Display.
4100-FP1046.
8U expansion CAB, window, Titania, suits PDI or legacy cards.
4100-FP1086.
8U expansion CAB blank door, Titania, suits PDI or legacy cards.
FP1029.
8U battery box, Titania.
4100-FP1087.
15U expansion CAB blank door, Titania, with 10A PSU.
4100-FP1088.
15U expansion CAB full window, Titania, 15U gear plate, 2x8
slot display doors.
Build to Order 4100ESi Series Base Fire Alarm Panels
15U Base panel.
4100ESi-CPU, InfoAlarm+, 10A PSU, 15U, MCP, 1x8 slot display
door (Titania) (no MX loop).
28U Base panel.
4100ESi-CPU, InfoAlarm+, 10A PSU, 2x8 slot display doors
(Cream Wrinkle) (no MX loop).
28U NDU.
4100ESi NDU-2xCPU, InfoAlarm+, 10A PSU, 3x8 slot display
doors (Cream Wrinkle) (no MX loop).
40U Base Panel.
4100ESi-CPU, InfoAlarm+, 10A PSU, 3x8 slot display doors
(Cream Wrinkle) (no MX loop).
40U NDU.
4100ESi NDU-2xCPU, InfoAlarm+, 10A PSU, 3x8 slot display
doors (Cream Wrinkle) (no MX loop).
Build to Order 4100ESi Series Base Data Gathering panels (DGPs)
15U Base DGP.
15U 4100ESi DGP-CPU, Network Card (no media) 10A PSU
blank door.
28U Base DGP.
28U 4100ESi DGP-CPU, Network Card (no media), 10A PSU,
blank door, 3x rear bays, (Cream, Wrinkle).
40U Base DGP.
40U DGP-CPU, Network Card (no media), 10A PSU, blank door,
4x rear bays, (Cream, Wrinkle).
Build to Order 4100ESi Series Base Remote Transponder Units (RTUs)
8U Base RTU.
8U RTU TIC, 10A PSU, blank door (Titania), (fits 4x legacy cards
or 5 PDI cards, needs battery box).
28U Base RTU.
28U RTU TIC, 10A PSU, blank door, 3x rear bays, (Cream,
Wrinkle).
40U Base RTU.
40U RTU TIC, 10A PSU, blank door, 4x rear bays, (Cream,
Wrinkle).
Custom Build to Order Panels
8U, 15U, 28U, 40U.
Custom panels can be configured to suit the site requirements.
38U, 40U, IP65 or stainless
steel.
Custom stainless steel or IP65 cabinets can be configured to suit
site requirements.
Cabinet sizes
8U
440mm H x 550mm W x 210mm D.
15U
750mm H x 550mm W x 210mm D.
28U
1300mm H x 575mm W x 380mm D.
40U
1865mm H x 575mm W x 380mm D.
