Operation
20220596G 31
2.19 Multiple station system
In normal operation of multiple control units, control is
accessible from every control unit connected to the autopilot
system. One control unit is "active" and provides the user with
access to all functions and enables the user to change modes and
set the course for automatic course keeping. All remaining
control units are "inactive" and have no effect on course changes.
A single press on any of the mode buttons on an "inactive"
control unit will allow transfer of command and make it "active".
2.20 Lock function
The "LOCK" function is a safety feature included in the autopilot
system when you have more than one control unit installed. It
will disable all control units except for a single, user selected
control unit location.
When the "lock" function is in use, no transfer of command may
take place; only the "active" control unit stays in command.
To enable the "lock" function, make a quick double press on the
STBY button.
STBY
PWR
Quick double
ress to"Lock"
The display on the "active" control unit will first show a icon
and then the icon will alternate with the mode index.
The "locked" control units in the system will show:
Inactive
