Simrad AP21 and AP22 Autopilots
90 20220596G
Drive unit voltage selection
This menu option requires the installer to set the drive unit
voltage to the correct level. The selections are 12V, 24V or 32V
(32V only with J300X/J300X-40) and should be set to the
voltage specified for your drive unit.
Note ! Selection of improper voltage level for your drive unit may
damage both the drive unit and junction unit even if the
protection circuits in the junction unit are activated.
Refer to the drive unit table on page 60 for information. It is not
possible to select a higher voltage than the input voltage. The
CLUTCH/BYPASS voltage is automatically set to the same as
the drive unit voltage. In Rudder Test, the autopilot system will
automatically detect whether the drive unit is a reversible motor
or solenoid operated.
Boat type
Planing
Drive unit
voltage ---
To change the voltage selection, rotate the course knob.
Note ! The drive unit voltage setting does not apply when operating
solenoids on a continuous running pump/steering gear. Hence,
the output voltage to the solenoids will be the same as the input
voltage.
Proceed to next menu item by pressing STBD [>] button.
Rudder Feedback Calibration
Make sure the RF300 is installed and aligned as pr. instruction in
section 4.6 (or eventually section 4.28 for LF3000). This
function enables you to compensate for any non-linearity in the
transmission between the rudder and the rudder feedback.
Rudder feedbk
calibration
STBD --°
PORT --°
Confirm by rotating the course knob clockwise.
