Simrad AP21 and AP22 Autopilots
48 20220596G
Material:..................................... Epoxy coated aluminium
Environmental Protection:......... IP44
Temperature range:
Operation: ......................... 0 to +55 °C (+32 to +130 °F)
Storage:............................. –30 to +80 °C (–22 to +176 °F)
3.11 R3000X Remote
Dimensions:..... See Figure 3-10
Weight:............ 0,4 kg (0,9 lbs)
Protection......... IP56
Cable length:.... 7 m, shielded
Material: .......... Epoxy coated aluminium
Figure 3-10 R3000X - Dimensions
3.12 S35 NFU Steering Lever
Dimensions:.................. See Figure 3-11
Weight: .........................1,4 kg (3,1 lbs)
incl. 10 m cable
Protection...................... IP56
Power consumption: .... 6 mA
Max. inductive load:..... 4A/12-24VDC
60mA/110VAC,
25mA/220VAC
Figure 3-11 S35 - Dimensions
