DIP SWITCH SETTINGS
101 988-12718-003
12 DIP SWITCH SETTINGS
This section includes drawings of the different printed circuits boards in
the Control unit that include jumpers and DIP switches.
12.1 Compact MK2 Control unit
1 board in the Compact MK2 Control unit has jumpers and/or DIP switches
that may be used to configure the GC80/85 system.
Only a few of these jumpers/DIP switches are used in installation and pre-
running procedures for the Gyro compass. Refer
Jumper settings in
Compact MK2 Control unit
, page 49, and
DIP switch and jumper
settings
, page 51.
The following pages include drawings that show the location of jumpers
and/or DIP-switches, together with a short description of the different
settings.
