Simrad GC80 Compact MK2 - Output Specifications

TECHNICAL SPECIFICATIONS
79 988-12718-003
8.4 Output Specifications
Serial output signal 1
Circuits: ................................................................................................... 4
Electrical: .............................................................................. RS422/485
Baud rate:
GC80:..................................................................... 4800/38400 bps
GC85:................................................................................ 38400 bps
Note!
Baud Rate for GC85, refer Jumper settings on ICNT board, output serial
signal selection, page 106.
Data bits: ........................................................................................ 8 bits
Parity: .............................................................................................. None
Stop bits: ................................................................................................ 1
Transmit freq.:
GC80:.......................................................................... 1, 5, 10, 50 Hz
GC85:......................................................................... 1, 5, 10, 50 Hz
Output format:
Data no.1
$ HEHDT,xxx.x,T*hh<CR><LF>
Data no.2
$ HETHS,xxx.x,a*hh<CR><LF>
Data no.3
$ HEROT,-xxx.x,a*hh<CR><LF>
Data no.5
$ PTKM,HEALM,xxxx,x,xx*hh<CR><LF>
Serial output signal 2 *1
Circuits: ................................................................................................... 4
Electrical: .............................................................................. RS422/485
Baud rate:
GC80:.................................................................................. 4800 bps
GC85:................................................................................ 38400 bps
Data bits: ........................................................................................ 8 bits
Parity: .............................................................................................. None
Stop bits: ................................................................................................ 1
Transmit freq.:
GC80:.......................................................................... 1, 5, 10, 50 Hz
GC85:.......................................................................... 1, 5, 10, 50 Hz
Output format:
Data no.1
$--HDT,xxx.x,T*hh<CR><LF>
Data no.2
$--THS,xxx.x,a*hh<CR><LF>
Data no.3
$--HDG,xxx.x,xx.x,a,xx.x,a*hh<CR><LF>
When Gyro is
selected
When External
heading sensor is
selected
