ALARM MESSAGES AND CORRECTIVE ACTIONS
115 988-12718-003
Serial repeater:
XF1 to XF4: 1 A
For location and replacement of the fuses, refer to page 42 onwards.
No output on any repeater
Disconnect the power from the Control unit, and check the following fuse:
XF8: 10 A
For location and replacement of the fuses, refer to page 42 onwards.
Failure when powering ON the Gyro compass
If alarm codes and are generated simultaneously when the GC80
system is turned ON, the following procedure should be used to correct
the alarm situation:
1 Press the POWER button to turn OFF the system. Re-press the
button after 1 second.
2 If the alarm status remains, remove the power from the system and
verify the fuse for the inverter.
For location and replacement of the fuses, refer to page 42 onwards.
