Simrad GC80/85 Compact MK2 Gyro Compass
988-12718-003 70
7.3 The Extension menu overview
Main
category
Sub
category
Parameter/description
Default
value
Range
1.1.U Damping gain
Determines the damping (damping operation in
north-seeking motion = half cycle attenuation) and
represents a coefficient (ratio) to the standard value
stored in the software.
1.00 0.00 – 2.00
A-1
1.2.F Bearing servo gain
Determines the gain of the bearing servo loop where
phi Φ signal (deviation signal around rotor’s vertical
axis) is calculated, drives the azimuth step motor and
has the Sensitive element follow to the Gyro-sphere
vertical axis (around azimuth axis) rotation. Presents a
coefficient (ratio) to the standard value stored in
software.
1.00 0.00 – 2.00
1.3.S Horizontal servo gain
Determines the gain of the horizontal servo loop
where theta θ signal (rotor tilting angle signal) is
calculated, drives the horizontal DST and has the
Sensitive element follow to the Gyro-sphere tilting
angle (rotor tilting angle). Presents a coefficient
(ration) to the standard value stored in software.
1.00 0.00 – 2.00
1.4.u Leveling servo gain
Leveling motion (Sensitive element erection motion)
calculates X signal (equivalent inclination angle)
which is output from the Sensitive element and
relative inclination angle signal from HRZC board
controls to have the Sensitive element keep
horizontal. The value determines this control loop
gain. Presents a coefficient (ratio) to the standard
value stored in the software.
1.00 0.00 – 2.00
1.5.L (φ) Phi offset (°)
Offset value (°) around the vertical axis of Gyro-sphere
(rotor axis) and the Sensitive element.
0.00 -3.00 – 3.00
1.6.t
(θ) Theta offset (°)
Offset value (°) around the horizontal axis of Gyro-
sphere (rotor axis) and the Sensitive element.
0.00 -3.00 – 3.00
