Simrad GC80/85 Compact MK2 Gyro Compass
71 988-12718-003
Main
category
Sub
category
Parameter/description
Default
value
Range
A-1
1.7.G X signal pickup gain (v/°)
Distance of the Sensitive element share and the rotor
axis direction. Inclination angle around horizontal axis
is obtained equivalently by monitoring this signal. For
example, when north side of the rotor axis rises, the
Sensitive element follows to rise its north side and
then Gyro-sphere suspended by the suspension wire
moves to south side. X signal represents this amount
of movement (v/°). This parameter is only used for
GC85.
2.32 0.00 – 5.00
1.8.c Ks/H
Suspension wire twist torque. Fixed value.
1.477 1.000 – 2.000
1.9.r Maximum rate of turn (°/sec)
Maximum rate of turn in the turn rates which the
bearing servo system followed up to this moment
(°/sec).
NOTE: The maximum is measured after 3 hours from
system start.
NOTE: Reset this data after completion of installation!
0.00 -
1.A.F Maximum deviation of bearing servo (°)
Maximum deviation value in the bearing servo loop
that occurred up to this moment (°).
NOTE: The maximum is measured after 3 hours from
system start.
NOTE: Reset this data after completion of installation!
0.00 -
1.b.S Maximum deviation of horizontal servo (°)
Maximum deviation value in the horizontal servo loop
that occurred up to this moment (°).
NOTE: The maximum is measured after 3 hours from
system start.
NOTE: Reset this data after completion of installation!
0.00 -
