5.6 Preventive maintenance intervals
Local evaluations should be made to determine site-specific maintenance
intervals.
ACTION INTERVAL RECOMMENDED
Confirm that the value of each
repeater synchronizes with the
displayed true bearing on the
Operator panel.
Daily
Confirm that the displayed latitude
and speed are according to the
vessel’s actual latitude and speed.
Daily
Check connectors Every 6 months
Tighten fastening screws Every 6 months
Clean panels and cabinet Once a year or as required
Clean slip rings and brushes. Lightly
apply “WD40 oil”.
Every 2
nd
year
Replace sensitive element
MTBF (Mean Time Before Failure) is
35000 hours (4 years).
On vessels in critical operations we
recommend 4-5 years.
On vessels in non-critical operation
(can operate with backup) we
recommend 6-8 years or when it
fails.
5.7 Replacing the Sensitive element
Caution The Sensitive element should only be replaced by authorized Simrad
personnel.
Note! A special tool is required when installing the Sensitive element. This tool is
optional and must be ordered from Simrad (part no. 44174449).
Mechanical installation
Caution Use extreme caution when handling the Sensitive element! Do not tilt
the element. It is filled with oil and the top includes a ventilation
opening.
1 Ensure that the power is disconnected from the Control unit.
2 Remove the 4 screws securing the compass case, and carefully lift
the case upwards and away.
