TECHNICAL SPECIFICATIONS
77 988-12718-003
Pendulum function ................................................................................ refer page 29
8.3 Input specifications
Serial input signal (GPS)
Circuits: ................................................................................................... 1
Electrical: ................................................................ RS422/NMEA0183
Baud rate: ................................................................................ 4800 bps
Data bits: ........................................................................................ 8 bits
Parity: .............................................................................................. None
Stop bits: ................................................................................................ 1
Transmit freq.: ........................................................................... 1 – 5 Hz
Input format:
$--GGA,x,xx.x,N,xx.x,E,x,~*hh<CR><LF> *
$--GLL,xxxx.xx,N,xxxx.xx,E~*hh<CR><LF>
$--VTG,xx,T,xx,M,xx.x,N,xx,K*hh<CR><LF>
$--ZDA,xxxxxx.xx,xx,xx,xxxx,xx,xx*hh<CR><LF>
* Priority
Serial input signal (External heading)
Circuits: ................................................................................................... 1
Electrical: ................................................................ RS422/NMEA0183
Baud rate: ................................................................... 4800/38400 bps
Data bits: ........................................................................................ 8 bits
Parity: .............................................................................................. None
Stop bits: ................................................................................................ 1
Transmit freq.: ................................................... 1 – 50 Hz/20 – 50 Hz
Input format:
$--HDT,xxx.x,T*hh<CR><LF>
$--THS,xxx.x,a*hh<CR><LF>
$--ROT,x.x,a*hh<CR><LF>
$--HDG,xxx.x,xx.x,a,xx.x,a*hh<CR><LF>
Input data format must be the same as selected output data
format from the Control unit (HDT/THS). When powered ON,
the Gyro will automatically detect the external sensor’s baud-
rate.
Serial input signal (LOG)
Circuits: ................................................................................................... 1
Electrical: ................................................................ RS422/NMEA0183
Baud rate: ................................................................................ 4800 bps
Data bits: ........................................................................................ 8 bits
Parity: .............................................................................................. None
Stop bits: ................................................................................................ 1
Transmit freq.: ........................................................................ 1 – 50 Hz
