Simrad GC80/85 Compact MK2 Gyro Compass
988-12718-003 24
Displaying settings with external sensor connected
Display state Display Description
Normal operation
GYRO
EXT
or
GYRO
EXT
- True output bearing
- Active compass
The compass indication equals the sensor
selected as active compass (Gyro or external)
DISP
1
st
press on
DISP button
or
- Bearing
- Passive compass
DISP
2
nd
press on DISP button
- Gyro compass bearing without correction
- Active speed input source indication (GPS,
Manual, Log or Serial Log)
DISP
3
rd
press on DISP button
- Latitude
- Latitude indication: north (LA.n) or south
(LA.s)
DISP
4
th
press on DISP button
- Vessel speed
- Speed input indication
(GPS, Manual, Log or Serial Log)
DISP
5
th
press on DISP button
- Rate of turn in °/min
- Rate of turn indication
DISP
6
th
press on DISP button
- Error codes (up to 4)
- Error indication
