Simrad GC80/85 Compact MK2 Gyro Compass
988-12718-003 80
Data no.4
$--ROT,-xxx.x,a*hh<CR><LF>
Data no.5
$--PTKM,--ALM,xxxx,x,xx*hh<CR><LF>
INS (BAMS)
Circuits: ................................................................................................... 1
Electrical: ................................................................ RS422/NMEA0183
Baud rate: ................................................................................ 4800 bps
Data bits: ........................................................................................ 8 bits
Parity: .............................................................................................. None
Stop bits: ................................................................................................ 1
Transmit freq.:
Data no.1, 4: ............................................................................... 30 s
Data no.2, 3: ................................................. INDETERMINATELY
Output format:
Data no.1
$--HEALC,x,x,x,x.x,aaa,x.x,x.x,x.x… … *hh<CR><LF>
Data no.2
$--HEALF,x,x,x,xxxxxx.xx,a,a,a,aaa,x.x,x.x,x.x,a---
a*hh<CR><LF>
Data no.3
$--HEARC,xxxxxx.xx,aaa,x.x,x.x,a*hh<CR><LF>
Data no.4
$--HEHBT,x.x,a,x*hh<CR><LF>
STEP signal
Circuits: ................................................................................................... 1
Electrical: ................................................................. 24 V DC – 6 step/°
Alarm output
Potential free.............................................................................. NO/NC
Running contact
Potential free.............................................................................. NO/NC
Refer Jumper settings on ICNT board, page 106.
