Technical specifications
NSO evo3S MPU
Electrical
Supply voltage 9 - 31.2 V DC
Power consumption - Max 45 W
Power consumption - OFF 1 W
Recommended fuse rating 3 Amp
Low power standby mode Yes
Protection Reverse polarity and temporary over-voltage
to 36 V
Alarm output current 1 Amp
Processors iMX8 Quad Max (x2)
Environmental
Operating temperature range -15°C to +55°C (5°F to 131°F)
Storage temperature -20°C to +60°C (4°F to 140°F)
Waterproof rating IPX2
Interface/Connectivity
Ethernet 3 ports (1 & 2 are PoE (RJ45 socket))
USB 2 ports (USB-A)
NMEA 2000 1 port (Micro-C male, 1 LEN)
NMEA 0183 2 ports. Baud rate: 4800, 9600, 19200, &
38400 (via proprietary cable)
RS422 2 ports. Baud rate: 1200, 2400, 4800, 9600,
19200, 38400, 57600, 115200
Video input 2 ports (BNC female. NTCS or PAL format)
HDMI output 2 ports (type A, 60 Hz nominal)
• 800x600 (SVGA 4:3)
• 1024x768 (XGA 4:3)
• 1280x720 (HD 16:9)
• 1366x768 (WXGA)
• 1920x1080 (Full HD 16:9)
• 1920x1200 (WUXGA 16:10)
• 1280x800 (16:10)
• 1280x1024 (SXGA 5:4)
Data card reader 1 card slot (32 GB, SD card socket)
Physical
Material ABS plastic
Dimensions Refer to "Dimensional drawings" on page 38
Weight 1.0 kg (2.2 lbs)
Compass Safe Distance - Metric, imperial 50 cm (20")
